The BEVRLink Relay 8 ch V1 24V is a versatile and reliable relay board designed for use with the BEVRLink system or directly with Raspberry Pi, Rock or other microcontrollers. With 8 channels and spring terminals for easy connection, this relay board is perfect for quickly setting up test and automation systems. The board also features LED indicators for each relay, making it easy to monitor the status of your devices.
One of the main advantages of the BEVRLink Relay 8 ch V1 24V is its compatibility with the BEVRLink Manager boards. These boards are designed to quickly connect and address the pins between, for example, a Raspberry Pi 4 and the relay board. This means that you can easily connect your devices and start controlling them with your Raspberry Pi.
The relays on the BEVRLink Relay 8 ch V1 24V are of industrial quality and are designed in Sweden. They are capable of handling loads up to 5A 250VAC or 5A 30VDC, making them suitable for a wide range of applications. Additionally, the board features a 24V output connector that can be used to power the next board.
In conclusion, the BEVRLink Relay 8 ch V1 24V is an ideal choice for anyone looking for a reliable and easy-to-use relay board that can be easily connected to a Raspberry Pi or other microcontroller. With its high-quality relays and versatile design, it is perfect for use in a wide range of applications.
8 Relay module, with spring terminals and LED indicators for each relay. It powers other modules and manager boards connected through the easy to use BERVLink connector. You only have to connect the boards, power and then put in your controlled devices to the relays. A 5V I2C bus is used for the communication between the boards and the manager board that can be any SBC or microcontroller like Raspberry PI, PICO, ESP32 etc. All our Manager boards have 3.3V to 5V level shifter for the i2c logic so that managers like Raspberry Pi could be used. A modular design enables you to do your own casing or use our BEVRLink case with support for DIN rail mounting.
The 5V I2C bus is open to be used with your own I2C product and other brands using standard Dupont 2.54 mm wires. Making the possibilities endless to what you could control and automate with this system.
24V/1A DC Jack power input Size: 5.5x2.1mm
Relay coil supplied directly from power input, 15mA used by each relay active.
24V output connector to be used to power the next board or use to power 24 V loads connected to the relays.
Manager and Expansion connector
High-quality relays, loads up to 5A 250VAC or 5A 30VDC
Standard rail mount bottom case
Onboard LEDs for indicating relays status
Power Good Status LED, if the board doesn’t have enough voltage (4.7V) due to heavy load it will turn off the LED.
Plug and play if using a BEVRLink Manager Boards, no cables needed to connect to a Raspberry Pi
Good for quickly setting up test and automation systems
